No specification added.
Rated Power (V))
6200 W
AC Input Voltage
230 V
AC Input Voltage Range
165~280( Personal)
120~280(Home)
AC Rated Input Frequency
50Hz/60Hz(Auto
Detection)
AC Output Voltage Waveform
Pure Sine Wave
AC Output Voltage Regulation
230VAC+2%
AC Output Frequency
50Hz/60Hz
Communication
RS485/Mobile App
Max. PV Input Power
7000W
Efficiency(Peak) BAT to INV
94%
Transfer Time
Oms
Net Weight
8.0 kg
Battery Voltage
48V DC
Battery Voltage Range
42~60 Vdc
Protection Degree
IP20
Battery Max. PV Charging Current
120 A
Battery Max. AC Charging Current
80 A
Maximum PV Input Voltage
500Vdc
Maximum PV Input Current
27A
MPPt Tracking Voltage Range
80-450 Vdc
MPPt Track Efficiency
99%
Humidity
0% to 95%
Storage Temperature
-15°℃ to 60°C
Dimension
390*320*112 mm
..............
| Product Code |
83759 |
|---|---|
| Product Size |
No Product Size |
| Product Color |
No Product Color |
