No specification added.
Rated Power (V)
1200 W
AC Input Voltage
230 V
AC Input Voltage Range
165~280( Personal)
120~280(Home)
AC Rated Input Frequency
50Hz/60Hz(Auto
Detection)
AC Output Voltage Waveform
Pure Sine Wave
AC Output Voltage Regulation
230VAC+2%
AC Output Frequency
50Hz/60Hz
Communication
RS485/Mobile App
Max. PV Input Power
2000 W
Efficiency(Peak) BAT to INV
94%
Transfer Time
Oms
Net Weight
3.6 kg
Battery Voltage
12V DC
Battery Voltage Range
10.5~15 Vdc
Protection Degree
IP20
Battery Max. PV Charging Current
80 A
Battery Max. AC Charging Current
50 A
Maximum PV Input Voltage
300Vdc
Maximum PV Input Current
15A
MPPt Tracking Voltage Range
30-240V dc
MPPt Track Efficiency
99%
Humidity
0% to 95%
Storage Temperature
-15°℃ to 60°℃
Dimension
285*250*91 mm
,,,,,,,,,,,,
| Product Code |
85899 |
|---|---|
| Product Size |
No Product Size |
| Product Color |
No Product Color |
